VCI STRENGTH FABRIC ROLL - 90 GSM | VCI FABRIC ROLL | RUST-X


Size: 1000 MM X 100 MTR
Color: White Outside / Blue Inside
Price:
Sale priceRs. 7,200.00

Tax included Shipping calculated at checkout

Description

VCI Strength Fabric is made on tapeline plant using virgin PE/PP polymers for best strength and clarity. It is used in variety of applications ranging from food packaging, construction, metals packaging, green house, mulching etc.

RustX Strength Fabric is a woven fabric made on circular knitting machines from specialized high strength HDPE/PP resin with dosages of UV protection and optical brighteners made from Virgin polymers.

The fabric is woven on automatic lines to ensure adequate strength is achieved by a Warp and Weft structure of the material. Strength fabric by its name is symbolic to not just the advantage of High Strength but also excellent moisture penetrations properties and oxygen transmissions.

It is laminated on both sides with Poly Ethylene of approx 20 gsm-25 gsm on each side with a hot lamination process and cannot be easily peeled off. Strength Fabric is general white on the outside and blue on the inside unless there is a specific or customized colour preference by the client.

Strength Fabric generally is available in 8x8 or 10x10 mesh which means there are 8 -10 PE/PP fibres in each direction in a 1 sq inch area. It has an extremely low moisture penetration and hence can be used for protection again rain, snow or water for longer durations. The double lamination both on inner and outer hence protect the package.

RustX product is printed with RustX logo and patent numbers. All packages are printed with manufacturing date and shelf life of product.


FEATURES

  • Powerful and extreme toughness and pliability to conform to coil configuration
  • Multi-­­metal VCI protection for all surfaces
  • High stretch ability
  • Sharp edge resistance due to multi-­­molecular linking for increased strength
  • Minimal equipment investment with substantial reduction in labor costs
  • Increased production through-­­put
  • Eliminates cost and associated problems
  • Dry packaging compatible product
  • Quick to use, remove and easy to recycle.


TCHNICAL SPECIFICATION

Physical Properties

Test Method Value 65 GSM Value 100 GSM Value 120 GSM Value 160 GSM
Colour Visual
Clear Transparent
White/ Blue White/Blue
White/Yellow
VCI/NON VCI
NON VCI VCI VCI VCI
Tensile Strength MD
490 984 1088 1120

CD
320 782 868 890
Elongation MD
<20% <20% <20% <20%

CD
<20% <20% <20% <20%
Mesh
10x10 10x10 10x10 10x10
Fabric Weight
45 GSM 52-55 GSM 65-70 GSM 95 GSM
Lamination Outside
15-20 GSM 18-20 GSM 22-25 GSM 25-30 GSM
Lamination Inside

18-20 GSM
22-25 GSM 25-30 GSM
VCI Content

12-15 GSM 12-15 GSM 12-15 GSM
Material PP/HDPE HDPE PP/HDPE PP/HDPE PP/HDPE
Condensation Test DVI 514 Pass Pass Pass Pass
